Diagnostic procedure
Mazda 6 Service Manual: Glass panel adjustment
1. Fully close the glass panel.
2. Measure the gap and height between the glass panel and body.
3. If not as specified, loosen the glass panel installation screws and
reposition the glass panel.
Clearance
a: -0.8-1.2 mm {-0.032-0.047 in}
b: 0 mm {0 in}
4. Tighten the installation scre ...
Mazda 6 Service Manual: Variable intake-air system (vis) shutter valve actuator inspection (l3)
1. Remove the air hose. (See INTAKE-AIR SYSTEM REMOVAL/INSTALLATION.)
2. Disconnect the vacuum hose from the VIS shutter valve actuator.
3. Connect a vacuum pump to the VIS shutter valve actuator.
4. Apply vacuum and verify that the rod moves.
If the rod dose not move, replace the intake ma ...
