Mazda 6 Service Manual: Rear wiper arm and blade removal/installation

Mazda 6 Service Manual / Body electrical system / Wiper and washer / Rear wiper arm and blade removal/installation

1. Remove in the order indicated in the table.



2. Install in the reverse order of removal.

3. Adjust the rear wiper arm and blade. (See REAR WIPER ARM AND BLADE ADJUSTMENT)

Rear Wiper Arm Installation Note

Clean the rear wiper arm connector shaft using a wire brush before installing the rear wiper arm.


Rear wiper motor inspection
1. Disconnect the negative battery cable. 2. Remove the liftgate lower trim. (See LIFTGATE LOWER TRIM REMOVAL/INSTALLATION) 3. Disconnect the rear wiper motor connector. 4. Connect battery positi ...

Rear wiper arm and blade adjustment
1. Operate the rear wiper motor to set the wiper in the park position. 2. Set the rear wiper arm onto the ceramics end line. ...
