Mazda 6 Service Manual: Dtc u2021

Mazda 6 Service Manual / Braking system / On-board diagnostic (dynamic stability control) / Dtc u2021

Note

To warm up the engine completely, idle the engine and wait for more than 5 minutes.

Diagnostic procedure
